117
LEGACY
MaxPac AR700 6” Tube (AAM2135)
BOM ID Qty Item No Description
1 1 AM2262 BACKING PLATE, ROW MOUNT WITH COULTER MOUNT, AR700
2 1 AM2264 ASSEMBLY, AR700 MAXPAC ROW UNIT
2A 2 BP3213 GREASE ZERK
3 1 AP2125 SHANK, 1-1/4” X 2” EDGE BENT
4 1 AP2976 DECALS, AR 700-MAX PAC, 2 1/4” X 6’’
5 6 BP3034 NUT, HEX, 3/4”-10, GRADE 2, PLATED
6 6 BP3035 WASHER, LOCK, 3/4”, PLATED
7 4 BP3042 NUT, HEX, 1/2”-13, GRADE 2, PLATED
8 4 BP3043 WASHER, LOCK, 1/2”, PLATED
9 4 BP3095 HEX CAP SCREW, 3/4”-10 X 8”, GRADE 5, PLATED
10 2 BP3128 HEX CAP SCREW, 1/2”-13 X 2-1/2”, GRADE 5, PLATED
11 2 BP3141 HEX CAP SCREW, 3/4”-10 X 3”, GRADE 5, PLATED
12 2 BP3229 BOLT, CARRIAGE, 1/2”-13 X 2-1/2”, GRADE 5, PLATED
13 1 CM2311 KNIFE WASHER
To Next Page
