BLU-JET LEGACY - Stagger Brackets Offset 6 X 6 Mounting

64
LEGACY
Stagger Brackets Offset 6” x 6” Mounting
NOTE: Consult row spacing
diagram for placement of offset
stagger brackets.
BOM ID Qty Item No Description
1 1 AAM2141 BRACKET, OFFSET STAGGER, 22 X 8, 6 X 6,
W/ HARDWARE
2 1 AM4510 BRACKET, OFFSET STAGGER, 22 X 8
3 2 BP3350 U-BOLT, 3/4”-10 X 6”W X 7-11/16”L, PLATED
4 4 BP3034 NUT, HEX, 3/4”-10, GRADE 2, PLATED
5 4 BP3035 WASHER, LOCK, 3/4”, PLATED
BOM ID Qty Item No Description
1 1 AAM2123 BRACKET, OFFSET STAGGER, 22 X 20, 6 X 6,
W/ HARDWARE
2 1 AM4545 BRACKET, OFFSET STAGGER, 22 X 20
3 4 BP3034 NUT, HEX, 3/4”-10, GRADE 2, PLATED
4 4 BP3035 WASHER, LOCK, 3/4”, PLATED
5 2 BP3350 U-BOLT, 3/4”-10 X 6”W X 7-11/16”L, PLATED
BOM ID Qty Item No Description
1 1 AAM2128 BRACKET, EXTENSION, 14”, 6 x 6, W/HARDWARE
2 1 AM4543 BRACKET, EXTENSION, 14”, 6” MTG, W/ANTI-ROTATION
3 4 BP3034 NUT, HEX, 3/4”-10, GRADE 2, PLATED
4 4 BP3035 WASHER, LOCK, 3/4”, PLATED
5 2 BP3352 U-BOLT, 3/4”-10 X 6”W X 5-11/16”L, PLATED
BOM ID Qty Item No Description
1 1 AAM2130 BRACKET, EXTENSION, 26”, 6 X 6, W/HARDWARE
2 1 AM4542 BRACKET, EXTENSION, 26”, 6” MTG, W/ ANTI-ROTATION
3 4 BP3034 NUT, HEX, 3/4”-10, GRADE 2, PLATED
4 4 BP3035 WASHER, LOCK, 3/4”, PLATED
5 2 BP3352 U-BOLT, 3/4”-10 X 6”W X 5-11/16”L, PLATED
