BLU-JET LEGACY - Hub and Spindle Assembly

139
LEGACY
AM24024 Hub and Spindle Assembly
AM24024 GAUGE WHEEL LEG, PIN ADJUST
BOM ID Qty Item No Description
1 1 AP2023 BEARING CONE, LM 67048
2 1 AP2048 HUB CAP, 1513
3 6 AP2049 WHEEL BOLT, 1/2”-20 X 1”
4 1 AP2066 GREASE SEAL, CR 16289
5 1 AP2078 BEARING CONE, JL 69349
6 1 AP2123 HUB W/CUPS, 6 BOLT, 611301-6
6A 1 AP2077 BEARING CUP, JL 69310
6B 1 AP2123-Hub HUB, 6 BOLT, 611301-6
6C 1 AP2524 BEARING CUP, LM 67010
6D 1 BP3072 GREASE ZERK, 1/4”-28
7 1 AP2146 WASHER, SPINDLE, 2” X 1-1/16” X .134”
8 1 AP2426 PIN, COTTER, 5/32” X 1-3/4”
9 1 AP2811 NUT, SPINDLE, 1”-14
10 1 EM3700 GAUGE WHEEL LEG, PIN ADJUST
