48
LEGACY
Part of Bundle Number: 66000106
BUNDLE NUMBER 55000100 (PIN ADJUST GAUGE WHEEL)
Gauge Wheel With Pin Adjust & 25 x 7.50 x 15 Tire & Rim
Tractor side of tool bar
55000100 GAUGE WHEEL, PIN ADJUST 6” X 6” MOUNTING, 25-750-6-6 1 PAIR
BOM ID Qty Item No Description
1 2 AAM2768 WHEEL, 25 X 7.50-15, 4 PLY, 15 X 6 X 6, WHITE
1A 1 AP2001 RIM, 15 X 6 X 6, WHITE
1B 1 AP2017 TIRE, 25 X 7.50- 5,4 PLY, TERRA RIB
1C 1 AP2790 VALVE STEM, METAL
2 2 AM24024 ASSEMBLY, GAUGE WHEEL LEG, PIN ADJUST
3 2 AM24025 BRACKET, PIN ADJUST GAUGE WHEEL MOUNTING
4 4 AP2407 SNAP RING, 1” EXTERNAL, HEAVY DUTY
5 2 BM3650 PIN, 1” X 5-9/16” USABLE
6 8 BP3034 NUT, HEX, 3/4”-10, GRADE 2, PLATED
7 8 BP3035 WASHER, LOCK, 3/4”, PLATED
8 2 BP3051 PIN, 1” X 6”, HITCH, PLATED
9 4 BP3215 MACHINERY BUSHING, 1-1/2” OD X 1” ID, 14 GAUGE, PLATED
10 4 BP3350 U-BOLT, 3/4”-10 X 6”W X 7-11/16”L, PLATED
11 2 BP3511 PIN, COTTER, 3/16” X 1-3/4”
