BLU-JET LEGACY - Page 52

49
LEGACY
Decal Placement
1. 8 AP 2215 Decal, BLU-JET, 3” x 8”
2. 1 AP 2222 Decal, Stand Clear of Tongue, Tongue light
3. 1 AP 2231 Decal, FEMA, 2-1/2” x 1-1/2”
4. 4 AP 2234 Decal, Danger stand clear falling wing
5. 1 AP 2469 Decal, Safety Chain
6. 1 AP 2483 Decal, Danger, falling from equipment
7. 1 AP 2914 Decal, Warning, high pressure uid
8. 2 AP 2554 Decal, LEGACY 4.75” x 20.75”
3
6
2
7
8
1
8
4
Install on
bottom side
1
1
1
4
Install on
bottom side
1
1
1
1
Decal, Stand Clear of Tongue,
Tongue light
Legacy
TM
AP2554 8-09
c OMMeRcIaL c LaSS a PPLIcaTOR
Decal: AP 2554 8-09
Actual Size 4-3/4” x 20-3/4”
Color: Reex Blue
1/4” Round Corners
On FB5000 White Vinyl Material
The decals need to be masked.
Please Quote 4
Legacy
TM
AP2554 8-09
c OMMeRcIaL c LaSS a PPLIcaTOR
Decal: AP 2554 8-09
Actual Size 4-3/4” x 20-3/4”
Color: Reex Blue
1/4” Round Corners
On FB5000 White Vinyl Material
The decals need to be masked.
Please Quote 4
Install on
bottom side
4
4
Install on
bottom side
5
