BLU-JET LEGACY - Secondary Wing Extension to 50 Ft

47
LEGACY
Bundle: 66000125 Secondary Wing Extension To 50 Ft.
BUNDLE: 66000125 SECONDARY WING EXTENSION TO 50 FT.
BOM ID Qty Item No Description
1 2 AM4547 BRACKET, SPACER, 13-1/2” OAL
2 2 AM6189 LINKAGE, SECONDARY FOLD, AT6010
2A 2 BP3072 GREASE ZERK, 1/4”-28
3 2 AM6197 WING LINKAGE, 12-1/4”, W/ 1-1/4” HOLE
3A 4 BP3072 GREASE ZERK, 1/4”-28
4 2 AM6203 BRACKET, SPACER, 8” OAL
5 2 AM6204 BRACKET, ANGLED STAGGER
6 4 AP2711 SNAP RING, 1-1/4” EXTERNAL, HEAVY DUTY
7 2 BM3548 PIN, 1-1/4 X 4-3/4 USABLE, DOUBLE GROOVED, PLATED
8 2 BM3816 PIN, 1-1/4” X 9-13/16” OAL, WITH 13/32” HOLE, PLATED
9 2 BM3817 PIN, 1” X 6-7/8” OAL, WITH 13/32” HOLE, PLATED
10 32 BP3034 NUT, HEX, 3/4”-10, GRADE 2, PLATED
11 32 BP3035 WASHER, LOCK, 3/4”, PLATED
12 2 BP3096 HEX CAP SCREW, 3/8”-16 X 2-1/2”, GRADE 5, PLATED
13 2 BP3115 HEX CAP SCREW, 3/8”-16 X 2”, GRADE 5, PLATED
14 8 BP3141 HEX CAP SCREW, 3/4”-10 X 3”, GRADE 5, PLATED
15 4 BP3249 MACHINERY BUSHING, 1-7/8” OD X 1-1/4” ID, 14 GAUGE
16 4 BP3350 U-BOLT, 3/4”-10 X 6”W X 7-11/16”L, PLATED
17 8 BP3352 U-BOLT, 3/4”-10 X 6”W X 5-11/16”L, PLATED
18 4 CP2660 NUT, HEX LOCK, 3/8”-16, NYLOCK
19 2 DP4379 TEE, RUN, 6FJX-6MJ-6MJ, STL, 6602-6
20 2 DP4550 TEE, BRANCH, 6FJX-6MJ-6MJ, 6600-6
21 2 DP4579 CYLINDER, HYDRAULIC, 4-1/2” X 20”, SIDE PORTED, B450200BCDDA07B
22 4 DP4580 ADAPTER, 6MJ-10MSAE, 6400-6-10
