24
LEGACY
Center Section Area of Bundle 66000126
BOM ID Qty Item No Description
1 1 66000126 LEGACY MAIN FRAME & PRIMARY WINGS
2 2 AAM2437 HOSE RETAINER ASSEMBLY, CLOSED LOOP, 4X6 TUBE
2A 2 AM4015 HOSE RETAINER, CLOSED LOOP, 6” & 7” MOUNTING
2B 4 BP3001 NUT, HEX, 3/8”-16, GRADE 2, PLATED
2C 4 BP3002 WASHER, LOCK, 3/8”, PLATED
2D 2 BP3045 U-BOLT, 3/8”-16 X 6”W X 5”L, PLATED
3 13 AAM2438 HOSE RETAINER ASSEMBLY, CLOSED LOOP, 6X6 TUBE
3A 13 AM4015 HOSE RETAINER, CLOSED LOOP, 6” & 7” MOUNTING
3B 26 BP3001 NUT, HEX, 3/8”-16, GRADE 2, PLATED
3C 26 BP3002 WASHER, LOCK, 3/8”, PLATED
3D 13 BP3351 U-BOLT, 3/8”-16 X 6”W X 7”L, PLATED
4 1 AAM2639 MANUAL HOLDERW/ 6” X 4” MOUNTING
5 1 AAM2928 STOP ARM, W/ PLUNGER, DEPTH CONTROL
6 1 AAM2930 ADJUSTMENT LINKAGE, LEGACY DEPTH CONTROL
7 1 AAM4768 ASSEMBLY, TURNBUCKLE
8 1 AM2144 HITCH, CLEVIS
9 1 AM2145 BRACKET, HITCH STORAGE, 6” MOUNTING
10 1 AM2197 BRACKET, WRENCH STORAGE
11 1 AM2518 JACK, 9TWDL
12 1 AM2526 CRANK W/ GRIP, 90 LONG
13 3 AM4015 HOSE RETAINER, CLOSED LOOP, 6” & 7” MOUNTING
14 2 AM4415 HOSE RETAINER, OPEN LOOP
15 2 AM4442 HOSE RETAINER, CLOSED LOOP
16 1 AM4511 BRACKET, TURNBUCKLE SUPPORT MOUNTING
17 1 AM4512 TURNBUCKLE SUPPORT
18 2 AM4517 WING LOCK
19 2 AM4524 ROCKER, AT6020
19A 4 BP3072 GREASE ZERK, 1/4”-28
19B 2 BP3560 TENSION BUSHING, 1-1/2” X 1-1/4” X 1” OAL
20 2 AM4528 BRACKET, HOSE HOLDER W/ PRESSURE GAUGE MOUNT
21 2 AM4529 SAFETY LAUNCH TRIP, PRIMARY WING, AT 5000
22 1 AM4563 CYLINDER LUG, BOLT-ON 5” CYLINDER
23 2 AM4564 CYLINDER LUG, SCREW ADJUST
23A 2 BP3516 TENSION BUSHING, 1-1/4” X 1” X 1” OAL
24 2 AM4566 WING LATCH PIVOT, SECONDARY WING
25 2 AM4567 SPACER PIPE, 6-1/4” OAL
26 4 AM4568 SECONDARY WING LOCK PLATE
27 1 AM4759 TURNBUCKLE WRENCH, 3-1/16”
28 1 AM5155 TONGUE, CAT IV, HD, WEIGHTED
29 1 AM6163 WHEEL LEG, LH, W/ 2-3/4” SPINDLE LOOP
29A 1 BP3213 GREASE ZERK
29B 1 BP3516 TENSION BUSHING, 1-1/4” X 1” X 1” OAL
29C 2 BP3538 TENSION BUSHING, 2” X 1-3/4” X 1-1/2” OAL
30 1 AM6164 WHEEL LEG, RH, W/ 2-3/4” SPINDLE LOOP
30A 1 BP3213 GREASE ZERK
30B 1 BP3516 TENSION BUSHING, 1-1/4” X 1” X 1” OAL
