138
LEGACY
AAM2800 Hub and Spindle Gauge Wheel
AAM2800, 608 HUB, 2-3/4” X 16” SPINDLE, WITH TAPERED WHEEL NUTS
BOM ID Qty Item No Description
1 1 AP2082 BEARING CONE, LM 501349
2 1 AP2122 PIN, COTTER, 7/32” X 1-3/4”
3 1 AP2171 SPINDLE, 2-3/4” X 16”
4 1 AP2805 BEARING CONE, JLM 506849
5 1 AP2808 GREASE SEAL, CR 27394
6 1 AP2809 HUB CAP, 1609
7 8 AP2810 WHEEL NUT, 5/8”-18
8 1 AP2811 NUT, SPINDLE, 1”-14
9 1 AP2812 WASHER, SPINDLE, 2-1/8” X 1-1/16” X .250”
10 1 AP2821 HUB WITH CUPS, 8 BOLT, WITH STUDS, 308300-8
10A 1 AP2086 BEARING CUP, LM 501310
10B 1 AP2804 BEARING CUP, JLM 506810
10C 8 AP2814 BOLT, WHEEL STUD, 5/8”-18 X 2-1/4”
10D 1 AP2821-Hub HUB, 8 BOLT, 608
10E 1 BP3268 GREASE ZERK, 1/8” NPT
