LEGACY
AAM2800-1 Hub and Spindle
AM6198 DUALS, ROCKER, WITH SPINDLE LOOPS FOR 2-3/4” SPINDLE
AAM2800-1, 608 HUB, 2-3/4” X 16” SPINDLE, WITH FLANGE LOCK NUT
BOM ID Qty Item No Description
1 1 AP2082 BEARING CONE, LM 501349
2 1 AP2122 PIN, COTTER, 7/32” X 1-3/4”
3 1 AP2171 SPINDLE, 2-3/4” X 16”
4 1 AP2805 BEARING CONE, JLM 506849
5 1 AP2808 GREASE SEAL, CR 27394
6 1 AP2809 HUB CAP, 1609
7 1 AP2811 NUT, SPINDLE, 1”-14
8 1 AP2812 WASHER, SPINDLE, 2-1/8” X 1-1/16” X .250”
9 1 AP2821 HUB WITH CUPS, 8 BOLT, WITH STUDS, 308300-8
9A 1 AP2086 BEARING CUP, LM 501310
9B 1 AP2804 BEARING CUP, JLM 506810
9C 8 AP2814 BOLT, WHEEL STUD, 5/8”-18 X 2-1/4”
9D 1 AP2821-Hub HUB, 8 BOLT, 608
9E 1 BP3268 GREASE ZERK, 1/8” NPT
10 8 BP3287 NUT, HEX LOCK, 5/8”-18 FLANGE, SPIRALOCK THREAD
