27
LEGACY
Center Section Area of Bundle 66000126
BOM ID Qty Item No Description
13 3 AM4015 HOSE RETAINER, CLOSED LOOP, 6” & 7” MOUNTING
31 1 AM6172 FRAME, MAIN, AT6020
31A 1 BP3516 TENSION BUSHING, 1-1/4” X 1” X 1” OAL
32 4 AM6179 LINKAGE, CYLINDER LUG SUPPORT
33 1 AM6182 LINKAGE, TONGUE CYLINDER ARM
33A 4 BP3072 GREASE ZERK, 1/4”-28
33B 1 BP3516 TENSION BUSHING, 1-1/4” X 1” X 1” OAL
37 2 AM6202 CYLINDER LUG, BOLT-ON W/ NOTCH
37A 2 BP3516 TENSION BUSHING, 1-1/4” X 1” X 1” OAL
56 2 BM3465 PIN, 1-1/4” X 7-3/4” OAL, W/ 13/32” HOLE, PLTD
65 2 BM3664 PIN, 1-3/4” X 16-9/16” OAL, W/ 21/32” HOLE
66 12 BP3001 NUT, HEX, 3/8”-16, GRADE 2, PLATED
67 12 BP3002 WASHER, LOCK, 3/8”, PLATED
68 9 BP3003 NUT, HEX LOCK, 3/8”-16, GRADE 2, PLATED
69 6 BP3005 HEX CAP SCREW, 3/8”-16 X 1-1/2”, GRADE 5, PLATED
72 14 BP3019 NUT, HEX, 1”-8, GRADE 2, PLATED
73 6 BP3020 WASHER, LOCK, 1, PLATED
84 3 BP3096 HEX CAP SCREW, 3/8”-16 X 2-1/2”, GRADE 5, PLATED
89 6 BP3135 HEX CAP SCREW, 5/8”-11 X 3-1/2”, GRADE 5, PLATED
96 4 BP3200 HEX CAP SCREW, 1”-8 X 3-1/2”, GRADE 5, PLATED
97 8 BP3205 MACHINERY BUSHING, 2-1/2” OD X 1-3/4” ID, 10GA,PLATED
102 6 BP3291 HEX CAP SCREW, 1”-8 X 4”, GRADE 5, PLATED
107 10 BP3375 NUT, HEX LOCK, 5/8”-11, NYLOCK
115 1 DP4485
REPHASING CYLINDER, 3-3/4 X 12, PMS-AM-2558
