33
LEGACY
Primary Wing Right-hand Area of Bundle 66000103
BOM ID Qty Item No Description
3 13 AAM2438 HOSE RETAINER ASSEMBLY, CLOSED LOOP, 6X6 TUBE
3A 13 AM4015 HOSE RETAINER, CLOSED LOOP, 6” & 7” MOUNTING
3B 26 BP3001 NUT, HEX, 3/8”-16, GRADE 2, PLATED
3C 26 BP3002 WASHER, LOCK, 3/8”, PLATED
3D 13 BP3351 U-BOLT, 3/8”-16 X 6”W X 7”L, PLATED
13 3 AM4015 HOSE RETAINER, CLOSED LOOP, 6” & 7” MOUNTING
14 2 AM4415 HOSE RETAINER, OPEN LOOP
15 2 AM4442 HOSE RETAINER, CLOSED LOOP
18 2 AM4517 WING LOCK
19 2 AM4524 ROCKER, AT6020
19A 4 BP3072 GREASE ZERK, 1/4”-28
19B 2 BP3560 TENSION BUSHING, 1-1/2” X 1-1/4” X 1” OAL
21 2 AM4529 SAFETY LAUNCH TRIP, PRIMARY WING, AT 5000
23 2 AM4564 CYLINDER LUG, SCREW ADJUST
23A 2 BP3516 TENSION BUSHING, 1-1/4” X 1” X 1” OAL
24 2 AM4566 WING LATCH PIVOT, SECONDARY WING
25 2 AM4567 SPACER PIPE, 6-1/4” OAL
26 4 AM4568 SECONDARY WING LOCK PLATE
30 1 AM6164 WHEEL LEG, RH, W/ 2-3/4” SPINDLE LOOP
30A 1 BP3213 GREASE ZERK
30B 1 BP3516 TENSION BUSHING, 1-1/4” X 1” X 1” OAL
30C 2 BP3538 TENSION BUSHING, 2” X 1-3/4” X 1-1/2” OAL
36 1 AM6188 WING, PRIMARY, RH, AT6010
43 4 AP2215 DECAL, BLU-JET, 3” X 8”
46 4 AP2234 DECAL, DANGER STAND CLEAR FALLING WING
50 12 AP2711 SNAP RING, 1-1/4” EXTERNAL, HEAVY DUTY
57 4 BM3485 PIN, 1-3/4” X 12-1/8” OAL, W/ 21/32” HOLE, PLATED
59 2 BM3497 PIN, 1-3/4” X 14-3/4” OAL
60 2 BM3544 PIN, 1-1/4” X 9” USEABLE
62 2 BM3555 HEX BOLT, 1”-8 X 7-5/16”, FULL THREAD WELDED HEAD
66 12 BP3001 NUT, HEX, 3/8”-16, GRADE 2, PLATED
67 12 BP3002 WASHER, LOCK, 3/8”, PLATED
68 9 BP3003 NUT, HEX LOCK, 3/8”-16, GRADE 2, PLATED
69 6 BP3005 HEX CAP SCREW, 3/8”-16 X 1-1/2”, GRADE 5, PLATED
70 2 BP3006 HEX CAP SCREW, 3/8”-16 X 1”, GRADE 5, PLATED
72 14 BP3019 NUT, HEX, 1”-8, GRADE 5, PLATED
77 16 BP3038 NUT, HEX, 5/8”-11, GRADE 2
78 16 BP3039 WASHER, LOCK, 5/8”, PLATED
83 6 BP3072 GREASE ZERK, 1/4”-28
87 3 BP3115 HEX CAP SCREW, 3/8”-16 X 2”, GRADE 5, PLATED
89 6 BP3135 HEX CAP SCREW, 5/8”-11 X 3-1/2”, GRADE 5, PLATED
90 4 BP3136 HEX CAP SCREW, 5/8”-11 X 4, GRADE 5, PLATED
95 2 BP3179 HEX CAP SCREW, 1/2”-13 X 8, GRD 5, PLATED
97 8 BP3205 MACHINERY BUSHING, 2-1/2” OD X 1-3/4” ID, 10GA, PLATED
99 2 BP3244 NUT, HEX LOCK, 1/2”-13, PLATED
100 12 BP3249 MACHINERY BUSHING, 1-7/8” OD X 1-1/4” ID, 14GA, PLATED
102 6 BP3291 HEX CAP SCREW, 1”-8 X 4”, GRADE 5, PLATED
106 2 BP3354 U-BOLT, 5/8”-11 X 4” X 7-3/4”, PLATED
107 10 BP3375 NUT, HEX LOCK, 5/8”-11, NYLOCK
To Next Page
