PKG00234 Nurse Tank Hitch Assembly Parts
BOM ID Qty Item No Description
1 1 PKG00234 NURSE TANK HITCH ASSEMBLY, AT6020
2 1 AAM2931 ASSEMBLY, NURSE TANK HITCH, AUTO-LOK, W/O PIN
3 2 AM6220 BRACKET, HITCH MOUNTING, AT6010 NURSE TANK
4 1 AM6273 BRACKET, NURSE TANK HITCH MOUNTING, LOW
5 1 AM6278 LINKAGE, NURSE TANK HITCH, 12-3/4”
6 4 AP2711 SNAP RING, 1-1/4” EXTERNAL, HEAVY DUTY
7 1 BM3544 PIN, 1-1/4” X 9” USEABLE
8 1 BM3547 PIN, 1-1/4” X 5-3/4” USEABLE
9 2 BM3632 PIN, CATEGORY IV, UPPER LINK
10 8 BP3034 NUT, HEX, 3/4”-10, GRADE 2, PLATED
11 8 BP3035 WASHER, LOCK, 3/4”, PLATED
12 2 BP3135 HEX CAP SCREW, 5/8”-11 X 3-1/2”, GRADE 5, PLATED
13 12 BP3140 HEX CAP SCREW, 3/4”-10 X 2-1/2, GRADE 5, PLATED
14 4 BP3208 U-BOLT, 3/4”-10 X 6”W X 5-11/16”L, PLATED
15 4 BP3249 MACHINERY BUSHING, 1-7/8” OD X 1-1/4” ID, 14GA, PLATED
16 2 BP3375 NUT, HEX LOCK, 5/8”-11, NYLOCK
17 12 BP3442 NUT, HEX LOCK, 3/4”-10, TOP LOCK, GRADE C, PLATED
