LEGACY
Auto-Lok Nurse Tank Hitch AAM2931 Parts
BOM ID Qty Item No Description
1 1 AAM2931 ASSEMBLY, NURSE TANK HITCH, AUTO-LOK, W/O PIN
2 1 AM4533 HITCH, SWING SLIDE INSERT, STANDARD
3 1 AM4534 FLIPPER HITCH, STANDARD, NURSE TANK HITCH
4 1 AM4539 SAFETY LATCH
5 1 AM4540 BACKING PLATE, SAFETY CHAIN LOOP, STD NURSE TANK HITCH
6 1 AM6230 BRACKET, SAFETY CHAIN ATTACHMENT
7 1 AM6272 HITCH, NURSE TANK, MAIN FRAME
7A 1 AM4536 INSERT LATCH, NURSE TANK HITCH
7B 2 AP2407 SNAP RING, 1” EXTERNAL, HEAVY DUTY
7C 1 BM3551 PIN, 1” X 15-1/8” USEABLE
7D 2 BP3215 MACHINERY BUSHING, 1-1/2” OD X 1” ID, 14GA, PLATED
8 2 AP2585 DECAL, HITCH CAPACITY, 25000 LB
9 1 AP2711 SNAP RING, 1-1/4” EXTERNAL, HEAVY DUTY
10 1 BM3549 PIN, 1-1/4” X 5-5/16” USEABLE, GROOVED W/ ANTI-ROTATION PIN
11 1 BP3003 NUT, HEX LOCK, 3/8”-16, GRADE 2, PLATED
12 1 BP3006 HEX CAP SCREW, 3/8”-16 X 1”, GRADE 5, PLATED
13 1 BP3072 GREASE ZERK, 1/4”-28
14 1 BP3192 MACHINERY BUSHING, 1-7/8” OD X 1-1/4” ID X 10GA, PLATED
15 2 BP3257 GREASE ZERK, 1/4”-28, 65°
16 1 BP3442 NUT, HEX LOCK, 3/4”-10, TOP LOCK, GRADE C, PLATED
17 1 BP3449 HEX CAP SCREW, 3/4”-10 X 6”, GRADE 8, PLATED
