71
LEGACY
SealPro II (AAM2855) Disc Sealer
1” x 2” Shank Parts
Notched Blade Optional
AAM2855 SEALPRO II, 1” X 2” SHANK, 1 ROW
BOM ID Qty Item No Description
1 2 AM2481 ASSEMBLY, SEALER HANGER WITH BLADE MOUNTING
2 1 AM2485 ASSEMBLY, SEALER MOUNTING BRACKET
2A 1 AM2484 BRACKET, SEALER MOUNTING
2B 1 BM3643 PIN, 1-1/4” X 12-1/2” OAL, SEALER SHAFT
2C 2 BP3003 NUT, HEX LOCK, 3/8”-16, GRADE 2, PLATED
2D 2 BP3096 HEX CAP SCREW, 3/8”-16 X 2-1/2”, GRADE 5, PLATED
3 1 AM2486 SEALER ARM, LEFT HAND
3A 2 AP3115 BUSHING, SELF-LUBRICATED 1-1/4” X 1-1/4” LONG
4 1 AM2487 SEALER ARM, RIGHT HAND
4A 2 AP3115 BUSHING, SELF-LUBRICATED 1-1/4” X 1-1/4” LONG
5 4 BP3041 HEX CAP SCREW, 1/2”-13 X 2”, GRADE 5, PLATED
6 16 BP3042 NUT, HEX, 1/2”-13, GRADE 2, PLATED
7 16 BP3043 WASHER, LOCK, 1/2”, PLATED
8 8 BP3050 WASHER, FLAT, 1/2”, PLATED
9 8 BP3125 HEX CAP SCREW, 1/2”-13 X 1”, GRADE 5, PLATED
10 2 BP3162 PIN, ROLL, 3/8” X 2”, PLATED
11 2 BP3249 MACHINERY BUSHING, 1-7/8” OD X 1-1/4” ID, 14 GAUGE
12 2 BP3313 U-BOLT, 1/2”-13 X 2”W X 2-3/4”L, PLATED
