89
LEGACY
BOM ID Qty Item No Description
1 1 66000136 SUPERSHOOTER III SINGLE ASSY, LESS DISTRIBUTION
2 1 AAM3514 SUPERSHOOTER III/ SQUIBB COUPLER/ BODYGUARD III
3 1 AM6277 SUPERSHOOTER RISER, AUTO-LOK HITCH
4 4 BP3001 NUT, HEX, 3/8”-16, GRADE 2, PLATED
5 4 BP3002 WASHER, LOCK, 3/8”, PLATED
6 4 BP3005 HEX CAP SCREW, 3/8”-16 X 1-1/2”, GRADE 5, PLATED
7 6 BP3042 NUT, HEX, 1/2”-13, GRADE 2, PLATED
8 6 BP3043 WASHER, LOCK, 1/2”, PLATED
9 6 BP3050 WASHER, FLAT, 1/2”, PLATED
10 6 BP3126 HEX CAP SCREW, 1/2”-13 X 1-1/2”, GRADE 5, PLATED
11 1 CP2593 HOSE, NH3, 1-1/4” X 64”
12 1 DP4397 SWIVEL, 1-1/4” MP X 1-1/4” FP
13 1 66000137 DUAL SUPRSHTR III ADD-ON ASSEMBLY, W/HARDWARE & 64” HOSE
13A 1 AAM3514 SUPERSHOOTER III/ SQUIBB COUPLER/ BODYGUARD III
13B 1 AM7664 MOUNTING PLATE, DOUBLE SUPERSHOOTER
13C 12 BP3001 NUT, HEX, 3/8”-16, GRADE 2, PLATED
13D 12 BP3002 WASHER, LOCK, 3/8”, PLATED
13E 8 BP3005 HEX CAP SCREW, 3/8”-16 X 1-1/2”, GRADE 5, PLATED
13F 4 BP3115 HEX CAP SCREW, 3/8”-16 X 2”, GRADE 5, PLATED
13G 1 CM2313 BRACKET, COUPLER, DOUBLE, 1-1/4” NPT
13H 1 CP2522 NIPPLE, HEX, 1- 1/4” NPT, 3000 PSI TRIVALENT
13I 1 CP2593 HOSE, NH3, 1-1/4” X 64”
13J 1 CP2870 STRAINER, NH3, 1-1/4” FPT 20 MESH, CONTINENTAL
13K 2 DP4397 SWIVEL, 1-1/4” MP X 1-1/4” FP
14 1 CP2522 NIPPLE, HEX, 1- 1/” NPT, 3000 PSI TRIVALENT
15 1 CP2870 STRAINER, NH3, 1-1/4” FPT 20 MESH, CONTINENTAL
16 1 DP4397 SWIVEL, 1-1/4” MP X 1-1/4” FP
SuperShooter III Add-on Parts
Dual Assembly 66000137 and 66000136
