34 MT55 Operation & Maintenance Manual
RIDE-ON PLATFORM (HINGED) (OPTION) (CONT’D)
Procedure (Cont’d)
Using The Platform
Figure 27
A hinged ride-on platform [Figure 27] is available for use
on the mini track loader. It provides an area for the
operator to stand while operating the machine.
Never operate machine from the ground when platform is
installed. Always keep your hands on the controls and
feet on the platform while operating (Inset) [Figure 27].
Figure 28
Be aware of the increased length of the machine and the
increased swing radius with the platform installed
[Figure 28]. Keep bystanders well away from the work
area.
Figure 29
The platform can pivot up and down while using the
machine.
The maximum pivot angles are shown in [Figure 29].
WARNING
Never modify equipment or use attachments that are
not manufactured by Bobcat.
W-2481-1003
P-48577B
B-22752
20°
67°
B-22749
