787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Electronic Flight Bag - Controls
and Displays
Copyright © The Boeing Company. See title page for details.
10.70.2 D615Z003-TBC
Selection displays the Main Menu page. Also, selecting MENU while in transfer
(XFR) mode cancels the transfer mode.
Rocker switch changes the display brightness; upper portion brighter, lower
portion dimmer.
When applicable, selection activates the item adjacent to the line select key.
Selection increases or decreases the zoom level. Left + key to zoom in, right - key
to zoom out. Repeated selection brings zoom level to the maximum or minimum.
Selection displays a view of the off-side EFB screen onto the on-side display and:
• XFR displays in green text in upper right corner of the screen
• selections being made off-side are seen on the on-side display in real time
• XFR key (second push) exits transfer mode and returns display to the last
screen viewed prior to selecting XFR
Note: Selecting the MENU bezel key also exits the transfer mode and displays
the Main Menu page.
When applicable, selection activates the high-lighted item on the page.
Selection turns the display backlight on or off.
Note: This switch does not power on or off the EFB hardware, only the display
unit backlight.
Enables direct selection of soft keys and fields on the display screen, and in some
applications allows panning and scrolling.
Moves the viewing window over the display in the direction of the selected arrow.
3
MENU Key
4
Bright (BRT) DIM Control Switch
5
Line Select Keys
6
Zoom Keys
7
Transfer (XFR) Key
8
ENTER Key
9
Power (PWR) Switch
10
Touch Sensitive Screen
11
Arrow Keys
October 31, 2007
