787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Electronic Flight Bag - Controls
and Displays
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 10.70.3
Display Description
Soft keys for available applications display in white text with a gray background.
A magenta cursor appears on the display when the EFB key is selected on a CCD.
A magenta highlight box displays around an available application soft key when:
• the cursor is moved over the application’s soft key, or
• the soft key is touched on the screen
1
Available Applications
2
Cursor
3
Highlight Box
DSPL
DSPL
PWR
XFRPGDNPGUPMENU ENTER
BRT
DIM
MAIN MENU
PERFORMANCE
DOCUMENTS
VIDEO
TERMINAL CHARTS
IDENT PAGE
SYSTEM PAGE INITIALIZE FLIGHT
LOGBOOK
1
3
2
4
June 16, 2008
