787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Electronic Flight Bag - Controls
and Displays
Copyright © The Boeing Company. See title page for details.
10.70.58 D615Z003-TBC
After all three frames display individually, the next CYCLE VIEW displays the
three views all together without the chart. The next selection of CYCLE VIEW
returns to the beginning of the cycle.
Selection toggles between the split modes.
SPLIT MODE view is split so the plan view is displayed on top of the screen and
the Briefing Strip™, Profile View, or Minimums displays at the bottom.
UN-SPLIT MODE displays the entire chart (identical to a paper chart).
A specific mode is set as the default according to company set preferences.
This functionality is not available on the Preview Chart page.
Selection rotates the chart clockwise 90º. Select ROTATE again to return the
orientation to the original position.
This soft key is unavailable when the chart is being viewed in Split Mode.
Selection returns the chart to its original magnification after using the Rectangle
Zoom, Zoom In, or Zoom Out functions.
Selection initiates drawing a diagonal line across a specific area of the chart to
magnify. When the diagonal line expands, it creates a rectangle around the area.
The specified area of the chart is centered and zoomed to the maximum extent
possible proportional to the screen. Use RESET ZOOM to cancel the view.
2
SPLIT/UN-SPLIT MODE Soft Key
3
ROTATE Soft Key
4
RESET ZOOM Soft Key
5
Rectangle Zoom (horizontal rectangle with magnifying glass) Soft Key
August 14, 2009
