787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Performance Dispatch
Takeoff
787-8/
FAA
Category A Brakes
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC PD.10.9
Takeoff Obstacle Limit Weight
Flaps 15
Sea Level, 30°C & Below, Zero Wind
OAT Adjustments
OBSTACLE
HEIGHT
(FT)
REFERENCE OBSTACLE LIMIT WEIGHT (1000 LB)
DISTANCE FROM BRAKE RELEASE (1000 FT)
8 1012141618202224262830
10 456.2 512.7 543.3
50 424.1 467.3 507.6 531.2
100 395.0 435.3 467.6 500.1 520.2 533.3 543.5
150 372.1 410.8 444.1 470.6 496.5 512.7 524.9 534.0 541.5
200 352.7 392.3 425.0 451.1 472.3 494.1 507.8 518.8 527.3 534.2 540.1
250 336.1 376.5 408.7 434.7 455.8 473.4 492.4 504.2 514.0 522.2 528.6 534.2
300 322.8 362.6 394.4 420.2 441.5 459.1 474.1 491.0 501.4 510.3 517.8 524.1
350 310.8 350.0 381.5 407.3 428.7 446.5 461.4 474.7 489.8 499.2 507.2 514.2
400 338.6 369.8 395.5 417.0 435.0 450.2 463.2 475.1 488.9 497.3 504.7
450 328.2 359.1 384.7 406.2 424.3 439.8 453.1 464.6 475.3 488.0 495.7
500 318.5 349.2 374.7 396.2 414.5 430.1 443.6 455.4 465.6 475.4 487.2
550 309.5 339.9 365.3 386.9 405.3 421.1 434.8 446.7 457.2 466.4 475.3
600 301.1 331.3 356.6 378.1 396.6 412.5 426.4 438.5 449.2 458.6 467.1
650 293.2 323.2 348.4 369.9 388.4 404.4 418.4 430.7 441.6 451.2 459.8
700 285.8 315.6 340.7 362.1 380.6 396.7 410.9 423.3 434.3 444.1 452.9
750 308.4 333.3 354.7 373.2 389.4 403.7 416.2 427.4 437.3 446.3
800 301.6 326.4 347.7 366.2 382.4 396.8 409.4 420.7 430.8 439.9
850 295.1 319.8 341.0 359.5 375.7 390.2 402.9 414.3 424.5 433.7
900 288.9 313.5 334.6 353.1 369.4 383.8 396.7 408.2 418.5 427.8
950 282.9 307.4 328.5 347.0 363.2 377.7 390.7 402.2 412.7 422.1
1000 301.7 322.7 341.1 357.4 371.9 384.9 396.5 407.1 416.5
Obstacle height must be calculated from lowest point of the runway to conservatively account for runway
slope.
OAT (°C)
REFERENCE OBSTACLE LIMIT WEIGHT (1000 LB)
300 340 380 420 460 500 540
30 & Below0000000
32 -5.1 -5.9 -6.7 -7.4 -8.2 -8.9 -9.7
34 -10.3 -11.8 -13.3 -14.8 -16.3 -17.8 -19.4
36 -15.4 -17.7 -20.0 -22.2 -24.5 -26.8 -29.0
38 -20.6 -23.6 -26.6 -29.7 -32.7 -35.7 -38.7
40 -25.7 -29.5 -33.3 -37.1 -40.8 -44.6 -48.4
42 -30.4 -35.0 -39.6 -44.2 -48.8 -53.4 -58.0
44 -35.1 -40.5 -45.9 -51.3 -56.7 -62.2 -67.6
46 -39.7 -46.0 -52.2 -58.5 -64.7 -70.9 -77.2
48 -44.4 -51.4 -58.5 -65.6 -72.6 -79.7 -86.8
50 -49.0 -56.9 -64.8 -72.7 -80.6 -88.5 -96.4
February 15, 2010
