787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Performance Dispatch
Takeof f
787-8/
FAA
Category A Brakes
Copyright © The Boeing Company. See title page for details.
PD.10.10 D615Z003-TBC
Takeoff Obstacle Limit Weight
Flaps 15
Pressure Altitude Adjustments
Wind Adjustments
ALT (FT)
OAT ADJUSTED OBSTACLE LIMIT WEIGHT (1000 LB)
300 340 380 420 460 500 540
S.L. & Below0000000
1000 -12.9 -14.5 -16.2 -17.8 -19.4 -21.1 -22.7
2000 -25.8 -29.1 -32.3 -35.6 -38.9 -42.2 -45.4
3000 -34.5 -39.4 -44.2 -49.1 -54.0 -58.8 -63.7
4000 -43.3 -49.7 -56.1 -62.6 -69.0 -75.5 -81.9
5000 -52.7 -60.6 -68.5 -76.4 -84.3 -92.2 -100.1
6000 -62.2 -71.6 -80.9 -90.3 -99.6 -109.0 -118.3
7000 -71.1 -81.6 -92.1 -102.6 -113.1 -123.6 -134.1
8000 -80.0 -91.6 -103.3 -114.9 -126.5 -138.2 -149.8
9000 -89.9 -103.0 -116.2 -129.3 -142.5 -155.7 -168.8
10000 -99.8 -114.5 -129.1 -143.8 -158.5 -173.1 -187.8
WIND (KTS)
OAT & ALT ADJUSTED OBSTACLE LIMIT WEIGHT (1000 LB)
300 340 380 420 460 500 540
15 TW -63.5 -62.5 -61.5 -60.5 -59.5 -58.4 -57.4
10 TW -42.3 -41.6 -41.0 -40.3 -39.6 -39.0 -38.3
5 TW -21.2 -20.8 -20.5 -20.2 -19.8 -19.5 -19.1
00000000
10 HW 6.2 5.8 5.4 5.0 4.5 4.1 3.7
20 HW 12.4 11.6 10.7 9.9 9.1 8.3 7.4
30 HW 18.2 17.0 15.8 14.6 13.3 12.1 10.9
40 HW 24.0 22.4 20.8 19.2 17.6 16.0 14.4
With engine anti-ice on, decrease weight by 600 lb.
With engine and wing anti-ice on, decrease weight by 600 lb.
February 15, 2010
