787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Airplane General, Emergency
Equipment, Doors, Windows -
Dimensions
Copyright © The Boeing Company. See title page for details.
1.10.2 D615Z003-TBC
Turning Radius
The wing tip swings the largest arc while turning and determines the minimum
obstruction clearance path. All other portions of the airplane structure remain
within this arc.
[Option – 787-8]
[Option – 787-8]
CAUTION: Do not attempt to make a turn away from an obstacle within 15
feet (4.6 m) of the wing tip, or within 55 feet (16.8 m) of the
nose.
Nose Radius
98 Feet 10 Inches
Tail Radius
115 Feet 4 Inches
Center of Turn for Minimum
Turning Radius. (Slow
continuous turning with
minimum thrust on all engines.
No differential braking.)
Wing tip radius
139 Feet 4 Inches
Note: Minimum pavement width for 180
o
turn: 138 Feet 4 Inches
Minimum Width
of Pavement for
180
o
Turn
(30.1 Meters) (35.1 Meters)
(42.5 Meters)
W
in
g
T
i
p
R
a
d
iu
s
N
o
se
R
ad
i
u
s
Maximum
Steering
Angle 70
o
T
a
i
l
R
a
d
i
u
s
(42.2 Meters).
787-8
February 13, 2009
