787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Chapter 1Airplane General, Emergency
Equipment, Doors, Windows
Flight Deck Panels Section 20
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 1.20.1
1.20 Airplane General, Emergency Equipment, Doors, Windows-Flight Deck Panels
Airplane General, Emergency Equipment, Doors, Windows20 Flight Deck PanelsFl ight Deck Panels
Introduction
The panels shown in this illustration are representative of installed units and may
not exactly match the latest configuration. Refer to the relevant chapter’s system
description for the most current information.
Flight Deck Panels
Glareshield
Forward
Left
Sidewall
Overhead
Center
Control Stand
Aft Aisle Stand
Forward
Aisle Stand
HUD
HUD
Forward
Right
Left
Right
Sidewall
Forward
Right
Left
June 16, 2008
