787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Airplane General, Emergency
Equipment, Doors, Windows -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
1.30.4 D615Z003-TBC
Push - rings chime in cabin.
Rotate – adjusts overhead dome light brightness.
Rotate – adjusts overhead panel light brightness.
Rotate – adjusts glareshield panel light brightness.
Rotate – adjusts glareshield flood light brightness.
ON – overrides normal controls and illuminates the following lights:
• all illuminated indicator lights
• glareshield flood lights
• instrument panel flood lights
• aisle stand flood lights
• forward dome lights
Rotate (when the MASTER BRIGHTNESS switch is pushed on) -
• adjusts the brightness of all panel lights and displays (does not control:
dome lights, flood lights, area lights, HUD, standby compass, handset and
annunciators)
• overrides individual brightness control settings
• limits adjustment range of individual brightness controls
• has full adjustment range of all lights when all individual brightness
controls are set to the center detent
A black ring on the side of the inner switch is visible when the switch is out (OFF).
Push ON (in) – the MASTER BRIGHTNESS control is on.
Push OFF (out) – the MASTER BRIGHTNESS control is off.
OFF – the landing light is not illuminated.
ON – the landing light is illuminated.
Note: The nose gear landing lights cannot illuminate when the nose landing gear
is not down and locked. When the nose gear landing lights are ON, the taxi
lights are also illuminated.
2
CABIN CHIME Switch
3
DOME Light Control
4
Overhead (OVHD) PANEL Light Control
5
GLARESHIELD Panel (PNL) Light Control (outer)
6
GLARESHIELD FLOOD Light Control (inner)
7
STORM Light Switch
8
MASTER BRIGHTNESS Control (outer)
9
MASTER BRIGHTNESS Control (inner)
10
LANDING Light Switches
June 16, 2008
