787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Airplane General, Emergency
Equipment, Doors, Windows -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 1.30.17
Moving the door operating handle to the OPEN position disables:
• power assist for door opening
[Option – Rafts at every door]
• automatic slide/raft deployment
If the mode select lever is not fully on top of the green or red band, or the
automatic/manual symbolic indicators are flashing, the door mode is unknown.
Slide closed to protect the mode select lever against inadvertent movement.
Used to select the required mode; automatic for flight or manual for arrival.
CAUTION: Ensure the door mode is properly selected by positioning the
door mode select lever directly over the red or green band and
ensuring that the appropriate symbolic indicator is illuminated
steady and not flashing.
5
Unsafe area
6
Door Mode Select Lever cover
7
Door Mode Select Lever
February 15, 2010
