787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Airplane General, Emergency
Equipment, Doors, Windows -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
1.30.16 D615Z003-TBC
Red band.
Door is in the automatic mode if the mode select lever is on top of the red band
and the appropriate automatic indications are present. See items 2 and 3 below.
(Refer to Passenger Evacuation
in Chapter L, Section 10, for additional
information.)
When the door operating handle is moved to the OPEN position:
• the door is powered open
[Option – Rafts at every door]
• the slide/raft deploys
Note: If the door is opened from the outside, the mode select lever mechanically
moves to the manual mode position.
Indication light, symbolic of emergency slide use, is illuminated when the door
mechanism has completely reached the automatic mode position actuated by the
door mode select lever. If the door is not completely in the automatic mode, both
automatic and manual indicators flash.
CAUTION: Do not rely on the symbolic indication as a means of
determining if the door is in the automatic mode. Ensure the
door mode selector is directly on top of the red band, and the
automatic symbolic indicator is illuminated steady and not
flashing.
Indication light, symbolic of normal disembarkation, is illuminated when the door
mechanism has completely reached the manual mode position actuated by the
door mode select lever. If the door is not completely in the manual mode, both
automatic and manual indicators flash.
CAUTION: Do not rely on the symbolic indication as a means of
determining if the door is in the manual mode. Ensure the door
mode selector is directly on top of the green band, and the
manual symbolic indicator is illuminated steady and not
flashing.
Green band.
Door is in the manual mode if the mode select lever is on top of the green band
and the appropriate manual indications are present. See items 2 and 3 above.
1
Automatic mode
2
Automatic mode indicator
3
Manual mode indicator
4
Manual mode
February 15, 2010
