787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Airplane General, Emergency
Equipment, Doors, Windows -
Systems Description
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 1.40.3
Strobe Lights
The strobe lights are white anticollision strobe lights located on each forward wing
tip and on the tailcone.
Beacon Lights
The beacon lights are red anticollision strobe lights located on the top and bottom
of the fuselage.
Navigation Lights
The navigation lights are the standard red (left forward wingtip), green (right
forward wingtip), and white (aft tip of both wings and tailcone) position lights.
Logo Lights
Logo lights are located on the stabilizer to illuminate the airline logo on the
vertical tail surface.
Wing Leading Edge Illumination
Wing lights are installed on the fuselage and illuminate the leading edge of the
wing.
February 15, 2010
