787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Airplane General, Emergency
Equipment, Doors, Windows -
Systems Description
Copyright © The Boeing Company. See title page for details.
1.40.4 D615Z003-TBC
Exterior Lighting Locations
Flight Deck Lighting
Flight deck lighting is provided for panel illumination, area lighting and localized
illumination. Flood lights and light plates provide panel illumination. Dome lights
provide flight deck area lighting. Map lights and a single utility light provide
localized illumination.
Beacon Lights -
Fuselage (Red
Strobe)
Navigation Position
Lights - Rear Wing Tip
Left and Right (White)
Navigation Position
Lights - Tailcone Left
Strobe Lights -
Logo Lights - Left and
Right Stabilizer
Runway Turnoff
Wing Illumination
Navigation Position
Tip (Left Red, Right
Strobe Lights -
Left and Right
Taxi Lights -
Nose Gear
Landing Lights -
Landing Lights -
Left and Right Wing
Lights - Forward Wing
Tailcone Left and
Top and Bottom
Right (White)and Right (White)
Lights - Left and
Right Wing
Lights - Left and Right
Fuselage
Nose Gear
Green)
Forward Wing
Tip (White)
