Pilot Seat Adjustment
Observer Seats
The first observer seat is track mounted. The seat:
• adjusts vertically
• adjusts forward and aft
• reclines
• adjusts for lumbar support
The seat also has:
• a folding arm rest on the left side
• crotch strap
• inertial–reel shoulder harness
•lap belt
• adjustable headrest
1. Adjust the seat to the
upright position; sitting up
straight, looking straight
ahead.
3. Adjust the seat until:
• the top of the glareshield
appears as the edge of a
plane, and
• the crosshairs on the
top of the rudder pedal
adjustment crank
housing line up with the
4. The control column must
be in the neutral position.
2. The seat pan tilt must be
rotated fully forward.
top of the control column.
