The lumbar support can be adjusted using the manual control wheel and the
push-button on the left side of the seat. The left side armrest pitch can be adjusted
using the control knob under the armrest and can be stowed vertically for easier
seat access. The headrest angle can be adjusted by moving the cushion to the right
and rotating it.
The second observer seat is not adjustable. The seat has:
• crotch strap
• inertial reel shoulder harness
•lap belt
• folding seat cushion access to under seat stowage
FIRST OBSERVER’S SEAT – PORT SIDE VIEW
Horizontal
Control
In/Out
Lumbar Control
Adjustable Headrest
Armrest Adjustment
Control
Up/Down
Lumbar Control
Recline Control
Vertical Control
Work Table
