787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Airplane General, Emergency
Equipment, Doors, Windows -
Flight Attendant Rest
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 1.47.7
If smoke is detected in the overhead flight attendant rest:
• on the flight deck:
• the master caution light illuminates
• an aural caution alarm sounds
• a SMOKE REST UPR DR 4 EICAS caution message is displayed
• in the crew rest area:
• the smoke detector alarm indicator light will illuminate
• all area lights will illuminate
• the pulsating smoke detection system alarm horn sounds
• the air supply valves are closed and the area exhaust valves are opened
• at the entrance main control panel:
• the pulsating smoke detection system alarm horn sounds
• in the passenger cabin:
• the amber light above the entrance enclosure door flashes
• a continuous chime sounds in the passenger cabin at door 3L, door 3
cross-aisle, door 3R, door 4L, and door 4R
• the cabin attendant master call lights flash
• a SMOKE DETECTED DR4 UPR REST message appears on the
cabin management system control panels
Once the smoke clears, the red alarm indicator light extinguishes and the smoke
detector is sensitive to smoke again. Continue to monitor the area until the red
alarm indicator light extinguishes.
Note: When the smoke detector has been activated by smoke, lingering smoke in
the detector sensor may cause reactivation. Blowing air into the detector
sensor may clear lingering smoke.
Emergency Equipment
The overhead flight attendant rest emergency equipment includes:
• Halon fire extinguisher (1)
• portable breathing equipment (PBE) (2)
• flashlight (1)
Emergency Equipment Symbols
L
A
H
Halon
Extinguisher
FlashlightPortable
Breathing
Equipment
(PBE)
August 14, 2009
