787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Air Systems -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 2.10.11
[Option – Forward cargo A/C, English units]
[Option – No forward cargo A/C]
Selected by the FLT DECK TEMP and the CABIN TEMP controls.
[Option – Forward cargo A/C]
Selected by the FLT DECK TEMP, FWD CARGO A/C, and the CABIN TEMP
controls.
[Option – No forward cargo A/C]
Actual temperature sensed on the flight deck or the passenger zone.
[Option – Forward cargo A/C]
Actual temperature sensed on the flight deck, forward cargo compartment, or the
passenger zone.
1
Selected Temperatures (magenta)
2
Actual Temperatures (white)
MULTIFUNCTION DISPLAY
ANTI-ICE PACKS
CABIN AIR
FLT DECK
PASSENGER CABIN
AIR DISTRIBUTION
FLT DECK + B + D
TRIM HEAT
FLT DECK + A + C
TRIM HEAT
70
AFLT DECK
TEMP
MASTER
OCCUPANTS
CABIN
201
TRIM AIRLR
R PACKL PACK
COOLING
STBY
LOAD SHED
UPPER
RECIRC
LOWER
LOAD SHED
RECIRC
F
B
75
C
75
D
757575
FWD
AFT
BULK
3421
75
74 74 747474
40 70
ALTERNATE
VENT
LOAD SHED
L2L1 R1 R2
70
LOAD SHEDLOAD SHED
COMPRESSOR
1
2
