Uplinked clearances are preceded by the letters "UL". Clearances containing a
turn direction are also displayed preceded by "L" or "R".
Push – transfer the value from the lower line to the upper line. Lower line blanks
after the transfer.
Rotate – sets the AFDS commanded bank limit when in the heading select (HDG
SEL) or track select (TRK SEL) roll mode as follows:
• AUTO – varies between 15º – 25º, depending on TAS
• 10º, 15º, 20º, 25º or 30º – the selected value is the maximum, regardless of
airspeed
Rotate – sets heading or track in the heading/track window and on the PFDs
HUDs, and NDs.
Push –
• selects heading select (HDG SEL) or track select (TRK SEL) as the roll
mode
• displays HDG SEL or TRK SEL on the PFD and HUD roll flight mode
annunciator
• the AFDS controls roll to fly the selected heading or track
• bank is limited by the bank limit selector
Push –
• selects heading hold (HDG HOLD) or track hold (TRK HOLD) as the roll
mode
• displays HDG HOLD or TRK HOLD on the PFD and HUD roll flight
mode annunciator
• the AFDS commands wings level and holds the heading or track
established when wings level is established
Illuminated (white) – the heading/track HOLD mode is engaged.
4
Uplink Transfer (XFR) Switch
5
BANK LIMIT Selector (outer)
6
Heading/Track Selector (middle)
7
Heading/Track Select (SEL) Switch (inner)
8
Heading/Track Hold (HOLD) Switch
9
Heading/Track Hold Light
August 14, 2009
