Pitch and Stabilizer Trim Systems
Control Wheel and Column
Spring-loaded to neutral.
Push (both switches) –
• on the ground, directly moves the stabilizer
• in the air in normal mode, changes the trim reference airspeed
• in the air in the secondary and direct modes, directly moves the stabilizer
Rotate – deflects the ailerons, flaperons, and spoilers in the desired direction.
Push/pull – commands the airplane to pitch in the desired direction:
• in the normal mode, deflects the elevator and horizontal stabilizer
• in the secondary and direct modes, deflects the elevator
Does not move with pitch trim operation.
1
Pitch Trim Switches
2
Control Wheel
3
Control Column
1
2
3
October 31, 2007
