Flight Controls -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 9.10.13
L – Left
R – Right
No direction is shown when rudder trim is centered.
2
Flaperon Position
3
Aileron Position
4
Stabilizer Position
5
Rudder Position
6
Primary Flight Control System Mode
7
Elevator Position
8
Rudder Trim Position and Direction
