787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
10.10.4 D615Z003-TBC
PFD Reference Speeds
Displays the takeoff reference speeds V1, VR (displays R if VR is within 4 knots
of V1 or V2), and V2, selected on the CDU:
• displayed for takeoff
• NO V SPD is displayed if V speeds are not selected on the CDU
• V1 is displayed at the top of the airspeed indication when selected and if
the value is off the scale
• V1 and VR are removed at lift-off
• V2 is removed on climb-out:
• when flap retraction begins, or
• after 10 minutes have passed without flap lever movement, or
• after VREF has been selected (for a turn-back)
(Refer to Takeoff Reference Page 1/2
in Chapter 11, Section 40, for additional
information.)
1
Takeoff Reference Speeds
140
160
V1
VR
3
4
12
V2
100
220
220
260
200
0
1
24
9
2
1
140
120
180
15
5
REF
30/134
100
8
9
0
14
5
7
6
3
4
