Multifunction Keypad (MFK)
There are two MFKs on the forward aisle stand, one on each side of the lower DU.
Each MFK controls cursor position and operation on the on-side inboard DU and
on-side MFD on the lower DU.
Pushing the switch displays the associated format. Pushing the same switch a
second time causes the MFD format to be removed and the default format to be
displayed.
