787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Controls and Indicators
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 10.10.57
Push –
• + increases display brightness
• - decreases display brightness
Indicates airplane position with reference to the horizon.
Indicates airspeed when above 30 knots.
Push and hold at least two seconds –
• aligns horizon with the airplane symbol
• reset takes approximately ten seconds
• starts new initialization sequence if previous attempt failed (ground only)
Push – changes units of barometric reference.
Indicates the barometric setting selected with the barometric selector.
STD is displayed when selected with the barometric selector.
Automatically adjusts display intensity for ambient lighting condition.
The glideslope pointer indicates glideslope position relative to the airplane –
• the pointer is in view when the glideslope signal is received
• the scale is in view when the APP mode is selected
• the pointer and scale are removed when the B/CRS mode is selected
The localizer pointer indicates localizer position relative to the airplane –
• the pointer is in view when the localizer signal is received
• the scale is in view when either the APP or B/CRS mode is selected
Rotate – changes barometric setting.
Push –
• selects standard barometric setting (29.92 inches Hg/1013 HPA)
• if STD displayed, selects the preselected barometric setting
4
Display Brightness Switches
5
Airplane Symbol
6
Airspeed Indications
7
Attitude Reset (ATT RST) Switch
8
Hectopascal/Inch (HP/IN) Switch
9
Barometric Setting
10
Ambient Light Sensor
11
Glideslope Pointer and Scale
12
Current Altitude
13
Localizer Pointer and Deviation Scale
14
Barometric Selector (BARO)
February 15, 2010
