787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Primary Flight Displays (PFDs)
Copyright © The Boeing Company. See title page for details.
10.30.6 D615Z003-TBC
Large
FMC Position
ANP
Circle
RNP
RNP
Uncertainty
Below
VNAV Path &
Outside RNP
Boundary
Below
On
Above
VNAV Path
VNAV Path
VNAV Path
FMC
RNP
RNP
VNAV Path
Note: The vertical NPS display the
same relationship between
as the lateral NPS.
maneuver space and ANP
VERTICAL NAVIGATION PERFORMANCE SCALES
February 15, 2010
