787 Flight Crew Operations Manual
DO NOT USE FOR FLIGHT
Flight Instruments, Displays -
Primary Flight Displays (PFDs)
Copyright © The Boeing Company. See title page for details.
D615Z003-TBC 10.30.7
Instrument Landing System Indications
ILS glideslope and localizer deviation, frequency/identification, DME, course,
and marker beacon indications are provided.
The approach reference information appears above and to the left of the attitude
display. The ILS station identification or frequency, course, and (if available)
DME are displayed.
The marker beacon indication (OM – outer marker, IM – inner marker, or MM –
middle marker) is displayed in the upper right corner of the attitude display area.
The glideslope pointer and scale appear on the right side of the attitude indication.
The localizer pointer and scale appear at the bottom of the attitude indication.
Integrated Approach Navigation (IAN) Indications
FMC glidepath and FAC deviation, approach identifier, distance, and course are
provided.
The approach reference information appears above and to the left of the attitude
display. The IAN deviation source annunciation is below the approach data.
IAN glidepath and FAC deviation indications and alerts are displayed like ILS.
Deviation indications appear when a valid IAN approach is selected. IAN
approach deviations are not available with QFE selected in the FMC.
Approach Minimums
The selected radio altitude or barometric approach minimums set on the EFIS
control panel are displayed near the bottom left of the altitude display.
Heading/Track Indications
Selected heading/track information is displayed in the bottom section of the PFD
on the mini-map. Current heading is displayed under a pointer at the top of the
compass rose. The MCP selected heading bug is displayed on the outside of the
compass rose. The MCP selected track bug is displayed on the inside of the
compass rose.
Heading or track is displayed based on the position of the MCP HDG/TRK
reference switch. The selected heading or selected track is annunciated below and
to the left of the airplane symbol. The current heading/track reference
(MAG/TRU) is shown below and to the right of the airplane symbol. A line drawn
perpendicular to the edge of the compass rose from the invisible center depicts the
current airplane track.
[Option – Horizon line heading scale]
Heading information is also displayed on the Horizon Line Heading Scale.
