Technical data
www.bora.com
3 Technical data
Device dimensions PUXA
230290
R3
40
515
830
230 230
Ø175
27,5
Fig. 3.1 PUXA device dimensions top view
6
68
199
233
802
Fig. 3.2 PUXA device dimensions front view
400
63
487
Fig. 3.3 PUXA device dimensions side viewt
3.1 X Pure (PUXA, PUXU)
Parameter Value
Multiphase supply voltage 380-415 V 2N/3N
Single-phase supply voltage 220-240 V
Frequency 50 Hz/60 Hz
Maximum power consumption 7,6 kW
(4,4 kW / 3,6 kW)
Fuse protection/Three-phase power supply
Fuse protection/Two-phase power supply
Fuse protection/Single-phase power supply
3 x 16 A
2 x 16 A
1 x 32 A
(1 x 20 A / 1 x 16 A)
Dimensions (width x depth x height) 830 x 515 x 199 mm
Weight (incl. accessories/packaging) 23 kg (PUXA)
24,5 kg (PUXU)
Cooktop
Material surface glass ceramic
Power levels 1 – 9, P
Front cooking zone size 230 x 230 mm
Front cooking zone power setting output 2100 W
3000 W
Rear cooking zone size 230 x 230 mm
Rear cooking zone power setting output 2100 W
3000 W
Cooktop energy consumption (pan size)
Cooking zone 1 front left (150 mm) 179,4 Wh/kg
Cooking zone 2 back left (180 mm) 176,2 Wh/kg
Cooking zone 1 and 2 bridget (240 mm) 191,5 Wh/kg
Cooking zone 3 front right (150 mm) 174,7 Wh/kg
Cooking zone 4 back right (180 mm) 177,5 Wh/kg
Cooking zones 3 and 4 bridget (240 mm) 197,1 Wh/kg
Total (average) 182,7 Wh/kg
Extraction system (PUXA)
Power levels 1 – 9, P
Exhaust air connection BORA Ecotube
Recirculation system (PUXU)
Power levels 1-9, P
Recirculation connection (WxH) 445 x 137 mm
Recirculation filter (PUXU)
Maximum filter capacity 150 (1 year)
Tab. 3.1 Technical data X Pure (PUXA, PUXU)
