Device description
www.bora.com
The system basically differentiates between two different types
of acoustic signals:
Acoustic signal Purpose
Short individual beep (0.1 s) Confirmation of a selection
Sequence of beeps Interaction required
Tab. 5.5 Sounds
5.3 How the cooktop extractor
works
Depending on the model you purchased, the cooktop extractor
can be operated as an exhaust air or a recirculating air version.
Exhaust air mode
The air suctioned away is purified by the grease filter and
expelled into the open air via a duct system.
The exhaust air must not be expelled into:
XO
a smoke or exhaust gas flue that is in operation
XO
a shaft used for the aeration of rooms where fireplaces are
installed.
If the exhaust air is to be directed into a smoke or exhaust gas
flue that is not in use, the installation must be checked and
approved by the responsible heating engineer.
Recirculation mode
The air suctioned away is purified by the grease filter and an
activated charcoal filter and fed back into the room in which the
appliance is installed.
To prevent odours in recirculation mode, an odour filter must be
used. For hygiene and health reasons, the activated charcoal
filter must be replaced at the recommended intervals (see the
Cleaning and maintenance chapter).
i
In recirculation mode, ensure sufficient ventilation and
aeration to expel humidity.
5.4 How the induction cooktop
works
An induction coil is located underneath an induction cooking
zone. If the cooking zone is switched on, this coil creates a
magnetic field that acts directly on the base of the pot thus
heating it up. The cooking zone is only indirectly heated up by
the heat emitted by the pot. Cooking zones with induction only
work if the cookware has a magnetisable base.
The induction automatically takes into account the size of the
used cookware which means that only the area in the cooking
zone covered by the base of the pot is heated up.
XX
Observe the minimum pot base diameter.
5.2.4 7-segment display
Multi-function display Meaning
Fan display
1
–
9
Power levels
ßp
Power setting
0
Inactive
A
Automatic extractor function
n
Automatic after-run
F
Filter service
Multi-function
display
0
0
0
Time indication
e.g.
E
Error code
Cooking zone indicator Meaning
Cooking zone
indicator
1
–
9
Power level
ßp
Power setting
v
Warming level (Pure)
,
Warming level 1 (X Pure)
:
Warming level 2 (X Pure)
*
Warming level 3 (X Pure)
v
,
Pan size recognition
0
Inactive
H
Residual heat indicator
(cooking zone is switched off
but still hot)
E
Error
Tab. 5.3 Meaning of the 7-segment displays
5.2.5 Lighting
i
The operating panel has 2 different levels of lighting
(100% and 50%).
i
On principle the system adapts the lighting to the current
operating scenario. Relevant display elements are more
brightly lit and irrelevant ones are dimmed. Unavailable
functions are faded out.
Lighting Use
100% Function is active and selected
50% Function is inactive but can be selected
0% (no indicator) Function is unavailable
Tab. 5.4 Lighting
5.2.6 Sounds
i
The volume of the acoustic signals can be set in the
menu (0% to 100%).
i
The acoustic signal for the power button cannot be set
to 0.
i
Safety-relevant acoustic signals are always emitted with
the volume at 100%.
