7-3
Bosch Security Systems 05/10 BLCC100I
Solution 16
plus
Installation Manual Input Programming
Inputs > Commands >
Set Chime Zones
-
MENU 3-0-3
This menu allows you to program zones to be monitored when
chime mode is activated. Chime mode is ideal for monitoring
a front door in a shop, a pool gate or other entrance points.
To sound the keypad buzzer when a chime zone is opened
(faulted) See MENU 6-1-5 — Beeper Options. To activate Chime
mode enter PIN + [MENU], select the Commands option and use
the arrow keys to scroll to the Chime On/O menu.
Chime mode only works when the area is disarmed.
1) Enter [MENU] + [3] + [0] + [3] and use the up and down arrows
to highlight the area from the list then press [OK].
2) Use the up and down arrow keys to highlight the zone(s) you
want to program as Chime Zones then press [OK].
Alternatively, you can enter the zone number directly then
press [OK]. A tick mark displayed on the right side of the zone
name indicates that the zone is already set for chime.
Zn001 Zone 1 Name
Zn002 Zone 2 Name
Zn003 Zone 3 Name
Press OK or MENU
3) One of the following messages will be displayed depending on
the current zone programming.
Zone 1 Name Zn001
Zone Chime is OFF
To turn ON, Press ON
To Go Back Press OK
Zone 1 Name Zn001
Zone Chime is ON
To turn OFF, Press OFF
To Go Back Press OK
4) Press [ON] or [OFF] to toggle the zone to be monitored when
Chime Mode is turned on then press [OK] to save and exit or
[MENU] to exit without saving.
Inputs > Commands >
Set Part 2 Zones
-
MENU 3-0-4
This menu allows you to program which zones are to be
excluded or bypassed when an area has been turned On in Part
Mode 2.
1) Enter [MENU] + [3] + [0] + [4] and use the up and down arrows
to highlight the area from the list then press [OK].
2) Use the up and down arrow keys to select the zone(s) that you
want to disable in Part 2, then press [OK]. Alternatively, you
can enter the zone number directly then press [OK]. Zones
marked with a tick are active and will alarm in Part 2 mode.
Zn001 Front Door
Zn002 Main Bedroom
Zn003 Lounge Window
Press OK or MENU
3) One of the following messages will be displayed depending on
the current zone programming.
4) Press [ON] to arm the zone in Part 2 mode or press [OK] to exit.
Front Door Zn001
Is not armed in PART2
To Enable, Press ON,
To Go Back Press OK
5) Press [OFF] to disarm the zone in Part 2 mode or press [OK] to
exit.
Main Bedroom Zn002
Is a armed in PART2
To remove, Press OFF
To Go Back Press OK
Inputs > Commands >
Smoke Sensor Reset
-
-
MENU 3-0-5
This command allows you to reset smoke sensors. When
initiated this command will cause any outputs programmed as
Event Type 49 — Smoke Sensor GND in the chosen area to turn
o for 10 seconds.
1) Enter [MENU] + [3] + [0] + [5] and use the up and down arrows
to highlight the area that you want to reset the smoke
detectors in then press [OK].
Smoke detector reset in
Progress. Please wait
2) The keypad will automatically return to the menu when all
smoke detectors in the area has been reset.
Smoke detectors must have the negative power terminal
connected to an output programmed as Event Type 49 for this
command to work.
