BradyPrinter S3700 User Manual 5
Setup
Printer Components
Printer Components
1 Cover 7 Keyboard (flips down)
2 Power button (green) 8 Label exit chute
3 Cut label button 9 Cover release latch
4 Feed label button 10 USB type A Port, USB type B
Port and Ethernet Port
5 Touchscreen (flips out) 11 Power corder connection
6 Stylus 12 On/Off switch
1
2
3
4
5
7
8
9
12
11
10
6
