8.2 VarioGuide
General Information
The VarioGuide (55950) is an instrument holder that attaches directly to skull clamps in order to
navigate frameless biopsies and catheter placements.
Components
Figure 59
No.
Component Article No.
①
VarioGuide arm
②
VarioGuide Array and disc set
• Disc Set 1.8 mm to 4.0 mm for VarioGuide
• Disc Set 4.0 mm to 8.0 mm for VarioGuide
55950-40
• 55950-71
• 55950-72
③
VarioGuide Joint 2 (includes the array holder and telescope) 55950-50
④
• V-inset for GE Head Holder
• V-inset for IMRIS Head Holder
• V-inset for Mayfield Head Holder
• 52006
• 52005
• 52003
VarioGuide
102 Instrument User Guide Rev. 2.3 Cranial/ENT Optical
