3.2 Disposable Registration Markers
Introduction
Registration markers enable fiducial marker-based registration. The arrangement of the markers is
unique to each patient, helping prevent registration of the wrong patient.
NOTE: Registration markers are single-use items and must be disposed of after use.
Marker Types
Type Marker Color Use Article No.
Disposable Registration Marker CT (150 PCS) Blue CT 52150
Disposable Registration Marker OR (150 PCS) N/A OR 52152
Multi-Modality Donut Registration Marker N/A CT or MR 52160
Registration Marker CT (52150)
Figure 3
Part Quantity
Disposable CT markers (blue)
150 eachRegistration marker sockets
Marker plates on double-sided adhesive pads
NOTE: Store the kit within easy reach of the CT scanner.
NOTE: Store the CT markers in a cool, dry place, away from direct sunlight. Storage temperature
should not exceed 21 °C.
Registration Marker OR (52152)
Figure 4
Disposable Registration Markers
26 Instrument User Guide Rev. 2.3 Cranial/ENT Optical
