9.8.4 Connection to Kolibri
How to Connect
Connect the supplied cables between the microscope ports and the corresponding ports on the
Kolibri system according to the following diagrams.
Zeiss OPMI Neuro CRT/MultiVision
Figure 117
Zeiss OPMI Pentero/Pentero C/PENTERO 800/PENTERO 900/VARIO 700
Figure 118
NOTE: Image injection is not available for OPMI VARIO 700.
Zeiss OPMI Vario
Figure 119
NOTE: Image injection is not available for OPMI Vario.
Connection to Kolibri
142 Instrument User Guide Rev. 2.3 Cranial/ENT Optical
