7.1.1 Components
Unique Fit Adapters
Array Transducer/
Probe
Adapters Fit Article No.
Ultrasound
Navigation
Adapter Array
(22595)
BK Medical
Ultrasound Navigation
Adapter Base
• BK 8862/8863/N11C5S
• BK N13C5
Unique
(recalibration
not required)
• 41860-35B
• 41860-40
Aloka
Ultrasound Clamp for UST
5268P-5/52114P (Aloka)
Standard 41860-1
• Adapter Base for UST
987/9104/9120 (Aloka)
• Ultrasound Integration
Adapter Base (Aloka
UST-9133)
Unique
(recalibration
not required)
• 41860-5
• 41860-36
Before You Begin
Warning
Before performing navigation, the ultrasound probe must be calibrated using the
Ultrasound Registration Phantom.
Warning
Any movement of the probe independent from the adapter will cause inaccuracy during
navigation, endangering the patient.
Before attaching an adapter to the ultrasound probe, make sure you select the correct
adapter for your probe.
Ultrasound adapters are designed for specific ultrasound probes. If it is difficult to attach
the adapter on the probe check if it is damaged or the correct type. Avoid using heavy
force when attaching the adapter as it could damage the ultrasound probe.
Additional Ultrasound Adapters
Ultrasound Adapter Product Name
41860-10A Ultrasound Clamp Aloka UST 995-7.5
41860-11 Ultrasound Clamp Hitachi EUPF 331
41860-12 Ultrasound Clamp Siemens P8-3 & 7,5 PL13 Rev.02
41860-15 Ultrasound Clamp V7 (Acuson)
41860-1A Ultrasound Clamp For UST 5268P-5 / 52114P (Aloka)
41860-2 Ultrasound Clamp B&K 8562
41860-20 Ultrasound Clamp Siemens 5.0/7.5 Microsector
41860-21 Ultrasound Clamp GE 10S Sectortransducer
41860-24 Ultrasound Adapter Siemens Sonoline C8-5
41860-25 Ultrasound Adapter VF13.5SP Siemens
41860-27A Ultrasound Adapter Toshiba PSF65AT
Components
