4.2 Multiple Tip Pointer Package
General Information
The Multiple Tip Pointer Package (B12201) is available with interchangeable tip geometries,
supporting a wide range of surgical approaches.
Components
Figure 12
Name Tip Length Curved Tip End Length Offset Article No.
Pointer Tip
95 mm 20 mm (-70° angle) 30° 55791-03
100 mm 20 mm (-90° angle)
0°
55791-04
60 mm
N/A
55791-05
115 mm 45° 55791-02
123 mm (3.4 diameter)
0°
55791-34
150 mm 55791-01
Handle for Multiple Tip Pointer 55791
Paint Pointer Tips
①
②
Figure 13
The paint pointer tips are designed for accessing sinus cavities and are available for use in
combination with Paint software features.
NOTE: Only use the paint pointer tips with the Handle for Multiple Tip Pointer.
No.
Component Length Article No.
①
Eraser Pointer Tip (Curved)
130 mm
55791-06
②
Tip Set for Paint Pointer 41783
POINTERS
