9.5.4 Connection to Kolibri
How to Connect
Connect the supplied cables between the microscope ports and the corresponding ports on the
Kolibri system according to the following diagrams.
Leica M500-N/M520
Figure 85
No. Component
①
Kolibri 2.0 CAN-BUS adapter cable (19514-03)
Leica M525/M720 (SAI)
Figure 86
No.
Component
①
Kolibri 2.0 CAN-BUS adapter cable (19514-03)
MICROSCOPES
Instrument User Guide Rev. 2.3 Cranial/ENT Optical 121
